After order for 3 weeks
High-performance 24-port managed switch with advanced L2/L3 features and PoE+ power for professional network infrastructures.
The SWM282 is a top-tier network switch combining 24 PoE+ ports delivering up to 30 W per port with a total PoE budget of 300 W, plus 4 SFP ports for fiber connectivity. The switch supports advanced industrial protocols PROFINET, MRP, and EtherNet/IP, making it an ideal solution for mixed industrial environments.
The device comes with RMS cloud management and a two-year license, enabling remote administration, configuration, and monitoring. With its non-blocking 56 Gbps throughput and support for jumbo frames up to 10,000 bytes, it ensures high performance even under heavy network traffic.
Industrial protocols and compatibility
The switch supports PROFINET Class B (optional), MRP client/manager roles for redundant topologies, and EtherNet/IP for integration with industrial systems. These features enable deployment in demanding industrial applications.
Advanced networking features
The device offers a complete set of L2+ functions, including loop protection, advanced VLAN management, a DHCP server with wildcard MAC, and static IPv4/IPv6 routing. QoS supports scheduling methods SP/WFQ/WRR.
Management and diagnostics
The RMS cloud platform provides centralized management, alerting, FOTA updates, and advanced diagnostics. Local tools include cable diagnostics, ping, traceroute, and the ability to reboot PoE on individual ports.
BASIC SPECIFICATIONS
Processor: Realtek 500 MHz MIPS-4KEc, 1 core
Memory: 128 MB DDR3 RAM
Ethernet ports: 24× RJ-45 10/100/1000 Mbps
SFP ports: 4× SFP
PoE standard: 802.3at/af, up to 30 W/port, total 300 W
Throughput: 56 Gbps non-blocking
MAC table: 8K entries
Power supply: AC 100–240 V, 50/60 Hz, C14 connector
Power consumption: 7.5 W (idle) / 325 W (max)
Dimensions: 483 × 234 × 44 mm
Weight: 2291 g
Operating temperature: 0 to +50 °C
Protection rating: IP30
| Brand | |
| Type specification : | Switch |
| Manufacturer : | TELTONIKA |
| Technical specification | |
| Fanless : | no |
| Homologation EN50155 : | no |
| Switching capacity (Gbps) : | 56 |
| Management : | yes |
| Norma : | 802.3at |
| Norma : | 802.3af |
| PoE-in : | ne |
| PoE-out : | 802.3af/at |
| PoE-out (quantity) : | 24 |
| Outdoor use : | no |
| Placement : | rack |
| Max. operating temperature (°C) : | 50 |
| Min. operating temperature (°C) : | 0 |
| Switch throughput (Mpps) : | 83,33 |
| Stackable : | ne |
| Ingress protection : | IP30 |
| OSI layer : | L3 static (L2+) |
| Display | |
| Display : | no |
| Network interfaces | |
| Gigabit LAN : | yes |
| LAN : | yes |
| Počet PoE portů : | 24 |
| Port Speed : | 1 Gb/s |
| Inputs and outputs | |
| RJ-45 : | 24 |
| RS-232 port : | no |
| SFP : | 4 |
| Card reader | |
| MicroSD card support : | no |
| Power supply | |
| Power type : | internal power supply |
| PoE support : | yes |
| Input Voltage (V) : | 100 - 240 (AC) |
| Warranty | |
| Warranty period EU (months) : | 26 |
| Warranty period CRN (months) : | 26 |
| Physical properties | |
| Color : | black |
| Weight (g) : | 2291 |
| Dimensions : | 483 × 234 × 44 mm |
| Additional equipment and features | |
| Certification mark : | CE, UKCA, CB, RCM, FCC, IC |
Code: NAPTPL1096
Code: NETH0040
Code: NAPUBT1059
Code: NAPUBT1101
